IS220PAICH2B Installation
Securely mount the terminal board of choice.
Insert the PAIC I/O pack directly into the terminal board connectors.
Use the threaded studs next to the Ethernet ports to mechanically secure the packs. The studs fit into a terminal board-specific mounting bracket. The bracket should be positioned so that no right-angle force is applied to the DC-37 pin connector between the pack and the terminal board. The adjustment should only be needed once during the product’s lifetime.
Depending on the system configuration, connect one or two Ethernet cables. The pack will work with either port. When using dual connections, it is common practice to connect ENET1 to the network associated with the R controller.IS420ESWBH3A(2)
Connect the pack to power by plugging in the connector on the pack’s side. Because the I/O pack has inherent soft-start capability that controls current inrush on power application, it is not necessary to disconnect power from the cable before plugging it in.
Configure the I/O pack as needed using the ToolboxST application.
IS220PAICH2B DiagnosticsIS420ESWBH3A(1)
The I/O pack runs the self-diagnostic tests listed below:

A power-on self-test that includes RAM, flash memory, Ethernet ports, and the majority of the processor board hardware; and
Continuous monitoring of the internal power supplies for proper operation.
A check of the terminal board, acquisition board, and processor board electronic ID information to confirm that the hardware set matches, followed by a check that the application code loaded from flash memory is correct for the hardware set.
Hardware limit checking is performed on each analog input based on preset high and low levels near the end of the operating range. When this limit is reached, a logic signal is generated and the input is no longer scanned. L3DIAG xxxx is a logic signal that refers to the entire board.
System limit checking is performed on each input based on configurable high and low levels. These limits can be used to generate alarms, enable/disable devices, and as latching/non-latching switches. RESET SYS clears the out of bounds.IS420ESWBH3A
Precision reference voltages are included in each scan by the analog input hardware. The measured values are compared to the expected values to confirm the health of the analog to digital converter circuits.
A small burden resistor is used to sense the analog output current on the terminal board. The I/O pack conditions this signal and compares it to the commanded current to ensure the digital to analog converter circuits are in good working order.
The analog output suicide relay is constantly checked for consistency between the commanded state and the feedback indication. The ToolboxST application provides information on individual diagnostics. Individual diagnostic signals can be latched and then reset with the RESET DIA signal if they become healthy.
World of Controls has the most comprehensive selection of GE Speedtronic Mark VIes control replacement components. Our experts are here to help you with your GE needs at any time. If you want any additional information, please contact WOC.
Frequently Asked Questions
What is IS220PAICH2B?
IS220PAICH2B is an Analog I/O Module developed by GE.
What is Noise suppression on inputs?
The ten circuits have a hardware filter with single pole down break at 500 rad/sec.
What is the Input converter resolution of the board?
The component comprises of 16-bit analog-to-digital converter
How to Obtain IS220PAICH2B?
WOC provides Mark VIe as well as other turbine control products. Contact World of Controls.
